ACX2367 - OEX Slimline Amber Led Beacon Fixed Mount Class 1

Boost your vehicle’s visibility and safety with the OEX Slimline Amber LED Beacon (ACX2367). Designed for professional use, this fixed-mount, Class 1 beacon is engineered for long life, durability, and high performance—perfect for emergency, construction, and utility vehicles.

Key Features & Benefits:

• Class 1 Certified: SAE J845, ECE R65 compliant for maximum legal visibility

• Super-Slim Design: Easy installation in tight spaces (Height: 48mm)

• Permanent Mount: Secure, fixed installation for reliability

• High-Output LED: 32 amber LEDs with 10 selectable flash patterns, including simulated rotate

• Weather & Vibration Resistant: IP67 waterproof, robust polycarbonate lens/housing

• Multi-Voltage: Operates on 12V or 24V systems (10–30V rating)

• Low Power Draw: Energy-efficient with minimal battery drain

• Long Service Life: Over 50,000 hours

• Two-Year Warranty: Built to last in tough NZ conditions

Technical Specifications:

• Part Number: ACX2367

• Type: Lamp Revolving Strobe Combo

• Brand: OEX

• Unit: Each

• Voltage: 12 or 24V (10–30V range)

• LEDs: 32 Amber LEDs

• Flash Rate: 10 selectable patterns (incl. simulated rotate)

• Mounting: Permanent (Fixed Mount)

• Beacon Style: LED

• Environmental: IP67 rated (dust/waterproof)

• Compliance: ECE R65, ECE R10 (EMC), SAE J845 Class 1

• Lens Colour: Amber

• Colour Output: Amber

• Height: 48mm

• Weight: 0.3kg

• Insulated Return: No

• Product Groups: Lighting > Emergency Lighting

• Warranty: 2 Years

Wiring Instructions:

• Blue wire: Earth

• Red wire: Positive

• Green wire: Momentarily touch to positive feed to change flash pattern

• Note: Light is not insulated or above ground. Blue wire must also be grounded.

Features:
• Permanent Mount
• SAE J845 Class 1
• 10 selectable flash patterns incl. simulated rotation
• ECE R10 EMC compliant
• IP67 waterproof
• Two Year Warranty

UPC Code: 9335854024137

Ideal for: Emergency, service, fleet, construction, and utility vehicles.
