Be Logsplitter - 35 Ton (W/O Engine)

BE 35-Ton Vertical/Horizontal Engine-Driven Log Splitter Frame – No Engine

Overview:

BE’s industrial-grade log splitter frame is designed for professional use, offering a high-quality, road- and farm-worthy build. Featuring a solid steel I-beam, towing package, and heavy-duty components, this frame is ready to be paired with your engine of choice, ideally the Honda GX270.

---

Key Features:

✅ Frame Only – Customize with Your Engine
✅ Easy Transition from Horizontal to Vertical Position
✅ 3-Position Control Valve with Auto Ram Return
✅ Extra-Wide Log Cradle – Keeps logs in place and catches split pieces
✅ Industrial-Grade Full I-Beam Construction – Prevents bending or twisting
✅ Tow Package – Includes 2" hitch, polymer fenders, and towing light kit
✅ Heavy-Duty Tapered Wheel Bearings
✅ Warranty: 2-year residential / 180-day commercial

---

Specifications:

• Splitting Force: 35 Tons
• Max Pressure: 3500 PSI
• Hydraulic Ram: 5" x 24"
• Hydraulic Pump Flow Rate: 60.5L/min
• Cycle Time: 11 Seconds
• Relief Valve Setting: 2500 PSI
• Maximum Log Size: 635mm (L) x 203mm (W)
• Supplied with Oil: Shell Tellus S2M #32
• Unit Weight: 249 kg
• Recommended Engine: Honda GX270

---

Recommended Accessories:

• Splitter 4-Way Wedge (LSTL98) – Part No. 85.802.038
• BE 35T Deluxe Log Splitter with Honda GX270 – Part No. LS35VTL-GX270

This rugged and reliable log splitter frame is ideal for high-output wood processing, ensuring efficiency and durability in the toughest conditions.
